Beta-ex electric wire rope hoist |
|
|
Rated load 320-7500kg Beta-ex electric wire rope hoist series products are designed in accordance with EU 94 / 9 / EG and mrl2006 / 42 / EG standards. This series of products can be used in various occasions, especially in some flammable and explosive occasions (such as air and combustible gas mixture, smoke / dust and air mixture). Beta-ex has stable gear motor, excellent workmanship and reliable use. Based on the special customized modular system, all kinds of hoists can be combined together conveniently. Excellent workmanship, the use of reliable and stable gear motor is a special feature of beta-ex. Product features The electronic control system is placed in the explosion-proof class ex II 2Gd de IIB T4 t 135 ℃. The electrical control part incompatible with ATEX is installed in the non explosion proof area, and the upper and lower hand drive auxiliary switch and emergency brake switch ensure the operation safety. There are up and down manual control buttons in accordance with ATEX specification and emergency stop buttons meeting the requirements of safe operation on the operating handle. Beta-ex standard overload protector with rated load over 1000kg Standard working voltage: 380 - 420v - 3 - 50Hz Insulation class: F Ambient temperature: - 20 ℃ to + 40 ℃ application area Chemical industry, petroleum, biogas, painting workshop and other flammable and explosive occasions. Product options Different temperature environment Different operating voltages When the carrying capacity is less than 1000 kg, there will be electrical overload protection Stepless speed regulation (stepless speed) Wire rope compactor of wire rope track drum Wire rope slack white action power off switch Gear limit switch Special surface coating treatment Multi layer reel or higher capacity reel Pulley block ATEX certified special wire rope and copper plated hook
|
