Global King Double-girder Wire Rope Hoist (Top Running) |
|
|
Rated load 5000-20000 kg Yale Global King wire rope hoist is specially designed for international market users who adopt metric standard. The company has 140 years of crane production experience, combined with new production technology and material technology, strict design standards and the use of high-quality product parts, in order to create this industrys wire rope hoist. Global King hoist is one of the competitive wire rope hoists in the market. It has the industrys safety product features, flexible configuration and a large number of product options, including longer lifting height, special control options and explosion-proof models facing dangerous environments. Because of these characteristics, we can ensure that the global King gourd is easy to use and has long service life even in heavy working environment. Characteristics of double beam wire rope hoist: 1. Wire rope reel The steel wire rope drum made of high-quality steel adopts deep groove design, and is also equipped with rope guide mechanism, which can effectively help the accurate rope arrangement of steel wire rope, ensure safe operation and prolong the service life of steel wire rope and drum. The top of the wire rope is equipped with three high-strength metal lock locks, and when it is in the low position of the hook, there are still three coils of allowance at the top to ensure the safety of operation. 2. High strength DC disc brake The braking performance of high-strength DC disc brake can reach 2 times of the standard torque, so as to realize fast and active braking and holding function. 3. Hoist motor Double speed hoist lifting motor, high-low speed ratio of 4:1, can meet your low-speed operation accurate positioning and high-speed operation of fast take-off and landing requirements. The design and manufacture of the motor are customized for the lifting industry. 4. Gear transmission mechanism The oil immersed gear transmission mechanism adopts three-stage speed reduction design, and the finished gear set runs in the anti leakage cast aluminum gear box. 5. Low clearance The low clearance design ensures the large traveling distance of the hook. 6. Limiter (not shown) The wire rope hoist is equipped with the upper and lower rotary chip circuit limiter as standard, and the touch type top limiter is optional. At the same time, the machine is equipped with overload protection device to ensure the safety of operation. 7. Rotatable hook The trolley is equipped with a rotatable hook, which can rotate freely in the range of 360 degrees horizontally and 180 degrees vertically to facilitate loading and unloading. Car characteristics: 1. Electronic gourd movement monitoring card Equipped with pulsetm monitoring card, it can record important information of operation, which is helpful for troubleshooting and reducing maintenance cost. In addition, pulse monitoring computer interface package is optional, which can easily read data in the computer. 2. Car The trolley mechanism can be easily adjusted to adapt to different track widths. The standard car has anti falling characteristics. Standard car anti-collision block. 3. Hoist and trolley control box The closed control box of the main engine and trolley control parts of the wire rope hoist has the protection level of NEMA 4 / 12. The main functions of the control part include: wire rope hoist action monitoring function (optional), motor overheating protection function and wire rope hoist overload protection function. Electrical components are easy to replace. The hoist motor and trolley can be adjusted at two speeds for smooth acceleration and accurate load positioning. 4. Trolley wheel The high strength steel trolley wheel can run smoothly on the square steel beam meeting ASCE standard or other requirements. There is a driving wheel on both sides of the car to drive the load to run smoothly and synchronously. The 5T trolley is driven by a single motor through gear reduction, and the wheels on both sides run synchronously. Other tonnage cars have dual drive.
|
