CPA pneumatic chain hoist hook or integrated trolley suspension mode |
|
|
Rated load 2000 - 10000 kg CPA type pneumatic chain block has all rated working levels and unlimited starts, which is an ideal choice for high-strength industrial applications. Its closed structure is not affected by external pollution, humidity and other media. It is mainly composed of three parts, which is very easy to maintain and economical. Product features The durable rotary piston motor has adjustable brake spring, which can effectively maintain the load even in case of sudden loss of air supply. The switch regulating valve inside the pneumatic motor ensures high starting torque. The control handle 4 buttons can sensitively control the work of the hoist and trolley, and is equipped with an emergency stop switch as standard. Large diameter muffler can effectively reduce the noise caused by exhaust. The normal working pressure is 4 to 6 bar. The planetary gear mechanism with oil immersed lubrication can provide extremely smooth operation and reduce the design size. The lifting chain wheel is designed with 5 chain sockets and made of steel with good wear resistance and high hardness. When it is used together with the standard lifting chain, it can ensure smooth and accurate lifting action. After precision machining, the guide chain groove is very strong and durable, and can be easily replaced. The upper and lower hooks are made of non aging and high toughness alloy steel, which will deform and not break suddenly when overloaded, ensuring the safety of users. The standard lifting chain has a hardened shell and galvanized surface, and the perfect cooperation with the hoist body can ensure the smooth and accurate operation. Product options It can be equipped with manual car or pneumatic car. Stainless steel lifting chain options. Pneumatic triplet options (including pressurizer, pressure gauge and lubricator).
|
