Lodestar 2T Single-reeve (ENT) |
|
|
Capacity: 2000 kg The CM entertainment Lodestar is now available as an economical 2-ton, single-reeved unit that’s ideal for a variety of lifting applications. And, because it’s a single-reeved unit, overall weight is decreased making it easier to transport and rig compared to a traditional double-reeved unit. BENEFITS & FEATURES LESS MAINTENANCE & EASIER INSPECTION ■ Brake location allows for quick access and easy inspection. ■ Lifetime grease-lubricated Gear Box means no oil change is required. ■ Clutch located outside the Gear Box allows for easy access which eliminates the need for complete disassembly and reduces downtime. IMPROVED SERVICEABILITY Easy access to the Clutch, Motor, Electrical Control Panel and Brake Assembly. LONGER SERVICE LIFE ■ Heavy-duty DC brake is designed for a long service life. ■ Lifetime grease-lubricated Gear Box and helical gearing ensures better wear and smooth operation. ■ Heavy-duty rated motors. IMPROVED LOAD SAFETY Clutch is located outside the load path preventing slipping of the load in an overload condition when the brake is not powered. IMPROVED CHAIN LIFE 5-Pocket Lift Wheel provides better chain and lift wheel engagement for smoother lifting and reduced vibration equating to less wear and a longer chain life. Zinc plating protects chain from environmental conditions. EASY ACCESS CONTROL PANEL Finger-safe wiring and plugand-play connectors on the Control Panel allow for quick change, easy access to terminal strips and simple fuse installation. ZINC PLATED LOAD CHAIN Designed and manufactured by Columbus McKinnon. 10 millimeter, zinc-plated Star Grade load chain protects against corrosion. Meets EN 818.7 Standards. ADJUSTABLE LIMIT SWITCH Easy-to-adjust screw limit switch automatically stops the hook at any predetermined point when either lifting lowering, preventing overtravel. OVERLOAD PROTECTOR Helps prevent lifting of dangerous overloads. METRIC RATED LIFETIME WARRANTY The industry’s best warranty against manufacturing and mate  rial defects.STANDARD ROTATABLE LIMIT SWITCH Designed for quick reset of limit position. SWIVEL OR RIGID HOOK SUSPENSION AVAILABLE OPTIONAL FEATURES DIRECT CONTROL Direct Control allows multiple motor units to be operated with a single control. D8+ Meets all Standard VPLT SR 2.0/SQP2 requirements. BGV-C1 Meets all standard C1 and DIN 56950 requirements. VARIABLE SPEED DRIVE (VFD) DOUBLE DC BRAKE Two independent acting DC Brakes for redundant braking. Field installation kit available. PRIMARY & SECONDARY TRANSFORMER FUSING |
